Removing the doors from your 2020 Jeep Wrangler is a popular way to enjoy open-air driving and make your vehicle feel more adventurous. Many owners love the freedom this brings, especially during warm months or off-road trips.
But getting the doors off safely is not just about unscrewing bolts. With the right steps, tools, and precautions, you can avoid damage and make the process smooth—even if you’re new to Jeep modifications.
Why Remove The Doors?
Driving your Jeep Wrangler without doors gives you a unique experience. It increases visibility, makes off-roading easier, and adds a fun, rugged look. According to Jeep, the Wrangler is designed for this, so you won’t void your warranty by removing the doors. However, some states require side mirrors for legal driving. Always check local laws before heading out.
Tools You Need
Before you start, gather these tools:
- T40 Torx bit
- Ratchet wrench
- Small container for bolts
- Soft cloth or towel
A T40 Torx bit is essential because Jeep uses these bolts for the door hinges. Having a towel or cloth helps protect paint and keeps bolts from rolling away.
Step-by-step Guide
Follow these steps to remove your doors safely and efficiently.
1. Prepare Your Jeep
Move your Wrangler to flat, stable ground. Turn off the engine and roll down the windows.
Rolling the windows down makes the doors lighter and easier to handle.
2. Disconnect Door Wiring
Open the door and locate the wiring harness under the dashboard. For the 2020 model, it’s a simple clip.
Press the release tab and pull the connector gently. This disconnects the power locks and windows.
3. Remove The Door Strap
There’s a check strap connected to the door frame. Lift it off the hook or pin. This prevents the door from swinging too far and helps with removal.
4. Unscrew The Hinge Bolts
Use your T40 Torx bit and ratchet to remove the two bolts from the hinges. Place the bolts in your container.
Some owners cover the hinge area with a towel to prevent scratches.
5. Lift Off The Door
Grip the door firmly. Lift straight up and away from the hinges. If it’s stuck, wiggle gently but don’t force it. Jeep doors can weigh between 45-60 lbs, so consider a helper if needed.
6. Store The Door Safely
Place the door on a soft surface, like a blanket or foam pad. Never lean it against a wall or hard floor this can cause dents or scratches.
Common Mistakes And How To Avoid Them
Many beginners make these errors:
- Forgetting to disconnect wiring – This can damage the harness.
- Losing bolts – Use a container and keep bolts labeled.
- Scratching paint – Always cover hinge areas and door edges.
- Lifting too hard – If the door feels stuck, double-check for missed bolts or clips.
A non-obvious tip: don’t rush. Take your time and check each step before proceeding.
Data Table: Jeep Wrangler Door Weight
Here’s a quick reference to help you plan:
| Door | Approximate Weight (lbs) | Helper Needed? |
|---|---|---|
| Front Door | 55 | Recommended |
| Rear Door | 45 | Optional |
Important Safety Tips
- Always disconnect the battery if you’re unsure about wiring.
- Wear gloves to avoid pinching fingers.
- Never force a door if it’s stuck. Double-check for hidden bolts.
An extra insight: Jeep recommends lubricating hinge pins with silicone spray before reinstalling doors. This makes future removal easier and prevents rust.
Comparison Table: Door Removal Vs. Door Kits
Thinking about aftermarket door kits? Here’s how they compare to removing factory doors:
| Feature | Factory Door Removal | Aftermarket Door Kit |
|---|---|---|
| Weight | 45-60 lbs | 20-35 lbs |
| Legal Mirrors | Need separate mirrors | Usually included |
| Weather Protection | None | Minimal |
| Installation Time | 15-30 min | 10-20 min |
Reinstalling The Doors
When you’re ready to put the doors back:
- Line up the hinges carefully.
- Slide the door back onto the pins.
- Reattach bolts, check straps, and wiring.
- Test power windows and locks before driving.
A tip many miss: check the torque on hinge bolts. Too loose and the door rattles; too tight and the bolts can strip.
Legal Considerations
Some states require side mirrors even when doors are off. Aftermarket mirrors that attach to the hinge or body are available. For more details on legal requirements, visit the National Highway Traffic Safety Administration.
Frequently Asked Questions
How Long Does It Take To Remove The Doors?
Usually, 15-30 minutes for all four doors. The first time may take longer as you learn the steps.
Do I Need Special Tools?
You only need a T40 Torx bit and a ratchet. These are included in the Jeep toolkit.
Will Removing Doors Affect My Warranty?
No. Jeep designed the Wrangler for this.
However, always handle wiring gently to avoid electrical issues.
Is It Safe To Drive Without Doors?
Yes, but you must install side mirrors for legal and safe driving. The ride will feel more exposed.
Can I Remove Doors By Myself?
It’s possible, especially for the rear doors. For front doors, a helper is recommended due to weight and size.
Removing the doors from your 2020 Jeep Wrangler is simple with the right tools and steps. With careful handling and attention to detail, you’ll enjoy a new driving experience. Always store your doors safely and follow local laws. Whether you’re heading to the trail or just want more fresh air, these tips will help you make the most of your Wrangler.
