Removing the rear windshield wiper from a Jeep Wrangler is a task many owners consider. Whether your wiper is broken, you prefer a cleaner look, or you’re installing a new accessory, doing this job yourself saves time and money. The process is straightforward but requires careful attention to avoid damaging the glass or the wiper assembly. Here’s a clear, step-by-step guide to help you safely and successfully remove your rear wiper.
Why Remove The Rear Windshield Wiper?
Most Jeep Wrangler models include a rear windshield wiper as a standard feature. Some owners find it useful for clearing rain and dust, especially if they drive off-road. However, there are good reasons to remove it:
- Aesthetic preference: Some people prefer the sleek, minimalist look without the wiper.
- Aftermarket upgrades: Adding a spare tire carrier, bike rack, or custom rear door setup may require removing the wiper.
- Malfunction: If the wiper is broken or stuck, removing it lets you replace or repair it.
- Reduced noise or vibration: Older wipers sometimes create unwanted noise or rattling.
Surprisingly, removing the rear wiper does not affect the operation of the front wipers or the main defrost system. The rear wiper is an independent component.
Tools And Materials Needed
Before you start, gather these items for a smooth process:
- Flathead screwdriver
- Socket wrench (usually 10mm or 13mm)
- Plastic trim removal tool (to prevent scratches)
- Small towel or rag
- Penetrating oil (if bolts are rusty)
- Safety gloves and glasses
Having the right tools reduces the risk of damaging the glass or paint.
Step-by-step Guide To Removing The Rear Wiper
Follow these steps to remove the rear windshield wiper from your Jeep Wrangler:
- Park and Power Off
- Make sure your Jeep is parked on a level surface.
- Turn off the ignition and remove the key for safety.
- Access the Wiper Arm Nut
- Lift the wiper arm away from the glass gently.
- Look for a small plastic cover at the base of the wiper arm. Pry it off using a flathead screwdriver or plastic trim tool.
- Underneath, you’ll see the mounting nut that holds the wiper arm to the motor shaft.
- Remove the Wiper Arm
- Use your socket wrench to loosen and remove the nut. If it’s rusty, apply a small amount of penetrating oil and wait a few minutes.
- Carefully wiggle the wiper arm. If it’s stuck, rock it gently back and forth; avoid using excessive force.
- Once loose, pull the arm off the shaft. Be careful not to scratch the glass.
- Remove the Wiper Motor (Optional)
- If you want a completely clean look or need to replace the motor, open the rear door to access the inside panel.
- Use the trim tool to gently pop off the inside panel (some models have screws).
- Unplug the wiring harness from the motor.
- Remove the bolts holding the motor in place and slide the motor out.
- Cover or Seal the Hole
- With the wiper arm and motor removed, you’ll have a small hole where the shaft was.
- Use a rubber grommet or plastic cap to seal the hole and prevent water leaks.
- Clean the area with a towel to remove dirt or residue.
Here’s a quick comparison of the key steps for just removing the arm versus removing the motor as well:
| Task | Wiper Arm Only | Wiper Arm + Motor |
|---|---|---|
| Time Needed | 10-15 minutes | 30-45 minutes |
| Interior Panel Removal | No | Yes |
| Sealing Required | Yes | Yes |
Important Tips For A Smooth Removal
- Be patient: If the wiper arm is stuck, avoid using hammers or prying tools that could crack the glass.
- Use plastic tools: Metal screwdrivers can scratch the paint or glass.
- Label screws and bolts: Keep all hardware in a small bag in case you want to reinstall the wiper later.
- Check for leaks: After sealing the hole, spray water to make sure no leaks are present.
Many Jeep owners are surprised to find that the rear washer fluid hose may still drip after removal. Pinch off or block the line if you remove the motor and want a clean finish.
What To Do After Removal
Once you have removed the rear wiper, consider these steps to finish the job:
- Install a cap or grommet: These are available at most auto parts stores and ensure your Jeep stays watertight.
- Clean the glass: Use glass cleaner to remove any smudges or fingerprints.
- Check your local laws: Some areas require rear wipers for road safety. Confirm the rules if you drive in harsh weather.
- Test the wiring: If you disconnected the motor, test your wiper switch to make sure it doesn’t trigger warning lights.
Here’s a quick comparison of popular wiper delete kits for Jeep Wranglers:
| Brand | Material | Weatherproof | Approx. Price |
|---|---|---|---|
| Mopar | Plastic | Yes | $12 |
| Rugged Ridge | Rubber | Yes | $10 |
| eBay Generic | Plastic | Somewhat | $7 |
Common Mistakes To Avoid
- Forcing the wiper arm: This can damage the motor shaft or break the glass.
- Skipping the seal: Leaving the hole open risks water leaks and rust.
- Losing parts: Save all bolts, nuts, and covers for future use.
- Not disconnecting the battery: For full motor removal, disconnect the battery to avoid electrical shorts.
Many beginners forget to seal the hole, leading to leaks during rain or car washes. Also, using the wrong size socket can strip the nut and make future removal harder.
Should You Remove It Yourself Or Go To A Pro?
Removing the rear windshield wiper is a project most Jeep owners can do with basic tools. However, if you are not comfortable with removing interior panels or dealing with wiring, a professional can do the job in under an hour.
DIY removal is cheaper and gives you flexibility. A shop may charge $50–$120 depending on local rates. Weigh your comfort with tools and risk of damaging your vehicle before deciding.
For more technical details on car wiper systems, check the Windshield wiper Wikipedia page.
Frequently Asked Questions
How Long Does It Take To Remove The Rear Wiper From A Jeep Wrangler?
Most people can finish the job in 10–45 minutes. Removing just the arm is quick, while removing the motor takes longer.
Will Removing The Rear Wiper Affect My Jeep’s Warranty?
Usually, removing the rear wiper does not void your warranty. However, damage caused during removal might not be covered.
Can I Reinstall The Wiper Later If I Change My Mind?
Yes, as long as you keep all original parts and hardware, you can reinstall the wiper arm and motor.
What Size Socket Do I Need For The Wiper Arm Nut?
Most Jeep Wranglers use a 10mm or 13mm socket. Check your model or consult your owner’s manual to be sure.
Is It Safe To Drive Without A Rear Wiper?
In most weather conditions, yes. However, if you drive in areas with heavy rain or snow, a rear wiper helps with visibility and safety.
With careful work and the right tools, removing your Jeep Wrangler’s rear windshield wiper is a simple and satisfying project. Take your time, follow the steps, and enjoy your Jeep’s new look or function.
